No.

Figure number

Gauge description

1

JIS C8303 Figure A.1
JIS C8282-1：2010 CL22.1

Maximum retaining force gauge (15A125V two-pole)

2

JIS C8303 Figure A.1
JIS C8282-1：2010 CL22.2

Minimum retaining force gauge (15A125V two-pole)

3

JIS C8303 Figure A.1
JIS C8282-1：2010 CL19

Test plug for temperature rise test (15A125V two-pole)

4

JIS C8303 Figure A.1
JIS C8282-1：2010 CL20/21

Breaking capacity, normal operation gauge

5

JIS C8303 Figure A.2
JIS C8282-1：2010 CL22.1

Maximum retaining force gauge (15A125V two-pole)

6

JIS C8303 Figure A.2
JIS C8282-1：2010 CL22.2

Minimum retaining force gauge (15A125V two-pole)

7

JIS C8303 Figure A.2
JIS C8282-1：2010 CL19

Test plug for temperature rise test (15A125V two-pole)

8

JIS C8303 Figure A.2
JIS C8282-1：2010 CL20/21

Breaking capacity, normal operation gauge

9

JIS C8303 Figure A.3
JIS C8282-1：2010 CL22.1

Maximum retaining force gauge (20A 125V two-pole)

10

JIS C8303 Figure A.3
JIS C8282-1：2010 CL22.2

Minimum retaining force gauge (20A 125V two-pole)

11

JIS C8303 Figure A.3
JIS C8282-1：2010 CL19

Test plug for temperature rise test (20A 125V two-pole)

12

JIS C8303 Figure A.3
JIS C8282-1：2010 CL20/21

Breaking capacity, normal operation gauge

13

JIS C8303 Figure A.4
JIS C8282-1：2010 CL22.1

Maximum retaining force gauge (20A 250V two-pole)

14

JIS C8303 Figure A.4
JIS C8282-1：2010 CL22.2

Minimum retaining force gauge (20A 250V two-pole)

15

JIS C8303 Figure A.4
JIS C8282-1：2010 CL19

Test plug for temperature rise test (20A   250V two-pole)

16

JIS C8303 Figure A.4
JIS C8282-1：2010 CL20/21

Breaking capacity, normal operation gauge

17

JIS C8303 Figure A.5
JIS C8282-1：2010 CL22.1

Maximum retaining force gauge (30A 250V two-pole)

18

JIS C8303 Figure A.5
JIS C8282-1：2010 CL22.2

Minimum retaining force gauge (30A 250V two-pole)

19

JIS C8303 Figure A.5
JIS C8282-1：2010 CL19

Test plug for temperature rise test (30A   250V two-pole)

20

JIS C8303 Figure A.5
JIS C8282-1：2010 CL20/21

Breaking capacity, normal operation gauge

21

JIS C8303 Figure A.9
JIS C8282-1：2010 CL22.1

Maximum retaining force gauge (15A 125V two-pole+ earthing-pin)

22

JIS C8303 Figure A.9
JIS C8282-1：2010 CL22.2

Minimum retaining force gauge (15A 125V two-pole + earthing-pin)

23

JIS C8303 Figure A.9
JIS C8282-1：2010 CL19

Test plug for temperature rise test (15A 125V two-pole+ earthing-pin)

24

JIS C8303 Figure A.9
JIS C8282-1：2010 CL20/21

Breaking capacity, normal operation gauge

25

JIS C8303 Figure A.10
JIS C8282-1：2010 CL22.1

Maximum retaining force gauge (15A 250V two-pole + earthing-pin)

26

JIS C8303 Figure A.10
JIS C8282-1：2010 CL22.2

Minimum retaining force gauge (15A 250V two-pole +earthing-pin)

27

JIS C8303 Figure A.10
JIS C8282-1：2010 CL19

Test plug for temperature rise test (15A 250V two-pole + earthing-pin)

28

JIS C8303 Figure A.10
JIS C8282-1：2010 CL20/21

Breaking capacity, normal operation gauge

29

JIS C8303 Figure A.11
JIS C8282-1：2010 CL22.1

Maximum retaining force gauge (15A 125V two-pole + earthing-pin)

30

JIS C8303 Figure A.11
JIS C8282-1：2010 CL22.2

Minimum retaining force gauge (15A 125V two-pole + earthing-pin)

31

JIS C8303 Figure A.11
JIS C8282-1：2010 CL19

Test plug for temperature rise test (15A 125V two-pole + earthing-pin)

32

JIS C8303 Figure A.11
JIS C8282-1：2010 CL20/21

Breaking capacity, normal operation gauge
